Bimetal Sheet
Bimetal Sheet- Cu-Al Clad Electrical Materials
—— Strong Bonded Bimetal Sheet
Perfect for Bimetal Bushings, Washers, Bearings, and Electrical Applications
- CuSn ALLOY
FB08G solid lubricating material FB09G bronze solid lubricating FB090 bronze material
is based on JF800 bimetallic material bearing is based on bronze material
CUPB22SN
🔹 Product Overview —— Bimetal Sheet
Our Bimetal Sheets are produced by metallurgically bonding two distinct metals—typically aluminum and steel or copper—through advanced rolling or explosive bonding techniques. These sheets offer a unique combination of light weight, corrosion resistance, and mechanical strength, making them ideal for high-performance industrial applications.
💡 Key Features —— Bimetal Sheet
Explosion Bonded Bimetal Sheet
Aluminum + Steel or Copper Composite
High Bonding Strength – Excellent interlayer adhesion
Good Conductivity & Corrosion Resistance
Reduces Weight without Sacrificing Performance
Machinable, Stampable, and Formable
Custom Thickness Ratios & Sizes Available
📐 Product Specifications —— Bimetal Sheet
Cu-Al bimetal, Clad sheet
Copper Alloy Powders Available:
· CuPb10Sn10 / CuPb24Sn4 / CuPb24Sn / CuPb30 / CuSn8Zn3
Steel Backing Material: SPHC
—— Al-Sn Bimetal Sheet
Material: AlSn20Cu / AlSn10Si4Cu AS104 / AlSn8SiCu / AlSn9SiCu / AlSn12Si4Cu / AlSn6Si2Cu1Ni / AlSn10Si3Cu / AlSn8Si2.50CuZr
AlSn7Si2.50CuZr / AlSn10Si3Cu2Zr / AlSn12Si2.3Pb1.7C uSb / AlSn6Si4Ni / AlSn6Si4CuMn / SA 260 (Japan) AlSu55i3.5Cr
Bimetallic Sheets:
· Thickness: 0.7 mm – 30 mm Width: ≤ 230 mm Length: < 2000 mm
Bimetallic Coils:
· Thickness: 1.5 mm – 4.0 mm Width: 80 mm – 180 mm
